Features
- New Quick Knockdown (QKD) facilitates rapid disassembly (and re-assembly) of components for inspection, cleaning and maintenance
- Anodized internal coating reduces corrosion and wear from abrasive fluids
- Expert (EXP) Series air motor
- Patented "Unstallable" unbalanced air valve design, which avoids stalling issues commonly associated with other pumps
- Exhaust valves that divert cold exhaust air from ice-prone components, which prevents freezing and downtime
- Ability to pass even large shear-sensitive solids without degradation or heat build-up
- BD Series pumps are often used for transfer, filling and recirculation and batching in Chemical, Printing (ink), Marine and General Industrial markets
Accessories
- 66109 Air Line Connection Kit contains Piggyback Filter/Regulator, pipe nipple and 5’ section of hose
- 637421 Air Section Service Kit
- 637494-XX Fluid Section Service Kit
- 637374-X Major Air Valve Assembly
Pump Casing Materials
- Aluminum
Diaphragm Materials
- Santoprene
- Hytrel
- PTFE Single Piece Composite
- PTFE w/ Santoprene backer
