ARO CF-200 End Suction Pump for Data Centers

Reliable Cooling Performance for Mission‑Critical Data Center Operations
The ARO CF‑200 End Suction Pump is a high‑performance centrifugal pump engineered specifically for data center cooling applications. Designed as part of the ARO CF Series, this pump delivers reliable, continuous liquid circulation to protect critical data center infrastructure from heat buildup. Built for efficiency, durability, and 24/7 operation, the CF‑200 supports stable thermal management in modern data center environments where uptime is essential.

Optimized for small to medium cooling loops, the CF‑200 provides smooth, high‑flow performance in compact installations. Its end suction design simplifies installation and maintenance, making it a dependable choice for operators seeking long‑term performance in data center cooling systems.

Key performance highlights:

Maximum Flow: up to 68.1 m³/h (300 GPM)
Maximum Head: up to 35 m (115 ft)
Fluid Ports (Inlet/Outlet): 2‑1/2" x 2" NPT
Material of Construction: Cast iron pump body
Maximum Solids Handling: up to 15.2 mm (0.6 in)
Motor: 5 HP, 230/460 V, Three Phase, TEFC

Designed for continuous duty, the ARO CF‑200 End Suction Pump delivers the reliability and efficiency required in data center cooling, where temperature stability directly impacts server performance and operational continuity.

The ARO CF‑200 End Suction Pump is a centrifugal pump dedicated to data center cooling applications requiring steady flow, moderate pressure, and compact installation. Cooling pumps in a data center play a critical role by circulating chilled liquid through advanced cooling loops, removing excess heat from servers and IT equipment. The CF‑200 is engineered to meet these mission‑critical demands with dependable performance and minimal downtime.

End suction centrifugal pump design for clean liquids
Compact, close‑coupled configuration for space‑constrained data center installations
High‑flow hydraulic performance with smooth, non‑pulsing output
Cast iron construction for durability and long service life
Stainless steel fasteners to reduce corrosion
Designed for continuous 24/7 operation in data center environments

Supports consistent thermal control in data center cooling loops
Helps protect servers and network equipment from overheating
Reduces maintenance needs through robust mechanical design
Simplifies installation in tight mechanical rooms common in data center facilities
Provides reliable performance backed by over 95 years of ARO expertise

Data center cooling loops
Server room liquid cooling systems
Chilled water circulation in data centers
Heat exchanger supply and return loops
Auxiliary cooling systems supporting critical IT infrastructure

Electric motors (up to 10 HP options available depending on configuration)
Mechanical seal material options (consult ARO for compatibility)
Mounting and connection accessories for data center installations

Pump Type: End suction centrifugal pump and motor unit
Maximum Flow: 68.1 m³/h (300 GPM)
Maximum Head: 35 m (115 ft)
Suction / Discharge Size: 2‑1/2" x 2" NPT
Pump Body Material: Cast iron
Fasteners: Stainless steel
Maximum Solid Size: 15.2 mm (0.6 in)
Motor Power: 3.7 kW (5 HP)
Voltage: 230/460 V
Phase: Three phase
Motor Enclosure: TEFC (Totally Enclosed Fan Cooled)

These specifications make the CF‑200 well suited for data center cooling systems that demand reliable flow, efficient heat transfer, and long operating hours.
