Drum Pump Packages: Basic Pump, Transfer or Dispensing

DAB05-XXXX-X-X

Non-metallic: 14.4 GPM (54.5 l/min)
Metallic: 12.0 GPM (45.4 l/min)



ARO pneumatic drum pumps are available in three body materials for optimum fluid compatibility. Choose from aluminum, stainless steel or polypropylene body construction.

Factory-Matched Package Components – Our Drum Pump Packages contain pre-specified, matching materials of construction for complete fluid compatibility.



Features:

  • 12.0 GPM (45.4 lpm) to 14.4 GPM (54.5 lpm) flow capability: drum pumps offer plenty of capacity to satisfy a broad range of transfer application volume demands
  • Stall-free operation: ARO diaphragm drum pumps feature a patented unbalanced air valve design that avoids stall-out, even under low air-inlet pressures
  • Bolted construction: ARO diaphragm drum pumps utilize bolted fasteners for leak-tight integrity
  • 5-year warranty

Drum Pump Packages can be ordered in three styles:

  • Basic: Pump, bung adapter, air safety shut-off, siphon tube, weather seal, and base
  • Complete / Transfer: basic pump plus fluid hose or fluid hose with non-drip nozzle
  • Complete / Dispensing: basic pump plus foot valve, hose and dispensing nozzle

Ratio: 1:1

Maximum Flow:
Non-metallic: 14.4 GPM (54.5 lpm)
Metallic: 12.0 GPM (45.4 lpm)

Displacement per cycle: 0.039 Gallons (0.15 Liters)

Air Inlet: (Female) 1/4 - 18 NPT/F

Fluid Inlet: Siphon tube for 55-gallon drum

Fluid Outlet: 1/2 - 14 NPT/F

Max. operating pressure: 100 PSI (6.9 bar)

Suspended solids max. dia.: 3/32” (2.4 mm)

Weight:
22 lbs. (10 kg) Polypropylene, basic package
26 lbs. (11.8 kg) Aluminum, basic package
36 lbs. (16.3 kg) Stainless, basic package

Model

Pump Housing & Seats

Pump Diaphragm & Balls

Lock Out Valve (104253-2)

Foot Valve

10' (3m) hose ASM

Dispense Valve

Fluid Service

DAB05-PPTT-2-A

Polypropylene

PTFE

X

-

-

-

Some Acids & Caustics*

DAB05-PPCC-2-A

Polypropylene

Hytrel

X

-

-

-

Oil

DAB05-PPUU-2-A

Polypropylene

Polyurethane

X

-

-

-

Oil

DAB05-PPAA-2-A

Polypropylene

Santoprene

X

-

-

-

Some Mild Acids / Mild Caustics*

DAB05-PPCC-2-N

Polypropylene

Hytrel

X

-

Nitrile

-

Oil

DAB05-PPCC-B-M

Polypropylene

Hytrel

X

X

Nitrile

No-drip

Oil

DAB05-PPAA-2-B

Polypropylene

Santoprene

X

-

EPDM

-

Some Mild Acids / Mild Caustics*

DAB05-PPUU-2-C

Polypropylene

Polyurethane

X

-

Vinyl

-

Oil

DAB05-PPCC-B-J

Polypropylene

Hytrel

X

X

Reinforced Nitrile

X

Oil

DAB05-PPAA-B-K

Polypropylene

Santoprene

X

X

EPDM

X

Some Mild Acids / Mild Caustics*

DAB05-SSTT-2-A

Stainless Steel

PTFE

X

-

-

-

Solvent

DAB05-ASTT-2-A

Alum / SS

PTFE

X

-

-

-

Solvent

DAB05-APCC-2-A

Alum / Poly

Hytrel

X

-

-

-

Oil / Service Fluids

DAB05-APCC-2-0

Alum / Poly

Hytrel

X

-

Nitrile

-

Oil / Service Fluids

DAB05-APCC-B-P

Alum / Poly

Hytrel

X

X

Nitrile

No-drip

Oil / Service Fluids

DAB05-APCC-B-D

Alum / Poly

Hytrel

X

X

-

X

Oil / Service Fluids

DAB05-APCC-B-L

Alum / Poly

Hytrel

X

X

Reinforced Nitrile

X

Oil / Service Fluids

DAB05-ASAA-2-A

Alum / SS

Santoprene

X

-

-

-

Water / Antifreeze
