ARO CF-300 End Suction Pump for Data Centers

High‑Flow, High‑Pressure Cooling for Large Data Center Circuits
The ARO CF‑300 End Suction Pump is a heavy‑duty centrifugal pump designed for demanding data center cooling applications requiring higher flow rates and stronger pressure. As part of the ARO CF Series, the CF‑300 supports continuous duty in large cooling circuits where thermal stability and reliability are critical to protecting servers and network infrastructure.

Engineered with a stronger cast iron body and stable pressure curves, the CF‑300 is well suited for circulating warmer liquids and managing higher hydraulic loads. This end suction centrifugal pump delivers smooth, consistent performance in mission‑critical data center environments where uptime cannot be compromised.

Key performance highlights:

Maximum Flow: up to 118.1 m³/h (520 GPM)
Maximum Head: up to 58 m (190 ft)
Fluid Ports (Inlet/Outlet): 3" x 2.5"
Material of Construction: Cast iron with stainless steel fasteners
Maximum Solids Handling: up to 11.9 mm (0.47 in)
Motor Power: up to 15 kW (20 HP)

Built for reliability and long service life, the CF‑300 delivers the performance required for modern data center cooling systems operating around the clock.

The ARO CF‑300 End Suction Pump is an end suction centrifugal pump dedicated to data center cooling loops with higher flow and pressure demands. Cooling pumps play a central role in a data center by moving chilled liquid through advanced thermal management systems. The CF‑300 ensures stable circulation to help prevent overheating and maintain optimal operating conditions for critical IT equipment.
Designed for larger circuits, the CF‑300 combines hydraulic efficiency with mechanical robustness. Its enclosed impeller design improves efficiency and bearing life, while the cast iron construction supports long‑term use in demanding data center environments.

End suction centrifugal pump optimized for clean liquids
Strong cast iron body with stainless steel fasteners
Stable pressure curves for consistent cooling performance
Enclosed, dynamically balanced impeller
Designed for continuous 24/7 operation
Suitable for warmer liquids commonly used in data center cooling

Supports reliable heat removal in large data center cooling loops
Helps protect servers, racks, and networking equipment
Reduces risk of downtime through stable hydraulic performance
Handles higher flow and pressure requirements efficiently
Backed by more than 95 years of ARO fluid handling expertise

Primary and secondary data center cooling loops
Chilled water circulation in large data centers
Heat exchanger supply and return systems
Liquid cooling infrastructure for high‑density server rooms
Industrial cooling systems supporting data center operations

Electric motors up to 20 HP
Mechanical seal material options (consult ARO for compatibility)
Installation and mounting accessories for data center systems

Pump Type: End suction centrifugal pump
Maximum Flow: 118.1 m³/h (520 GPM)
Maximum Head: 58 m (190 ft)
Inlet Size: 3 in
Outlet Size: 2.5 in
Materials of Construction: Cast iron
Fasteners: Stainless steel
Maximum Solid Size: 11.9 mm (0.47 in)
Motor Power: up to 15 kW (20 HP)

These specifications make the CF‑300 ideal for data center cooling systems that require higher capacity while maintaining efficiency and reliability.
