Maximum Flow: 184 GPM (696 LPM)
Maximum Discharge Pressure: 120 PSI (8.3 bar)
Fluid Ports Inlet/Outlet: 2” ANSI/DIN Hybrid Flange (Side or Center Ports)
Material of Construction: Polypropylene, PVDF, Conductive Polypropylene, Conductive PVDF
Maximum Solids: 1/4 inches (6.4 mm)
Maximum Dry Suction Lift: 19.5 feet (5.9 meters)
ARO EXP 2” non-metallic pumps achieve flow rates of up to 184 GPM (696.4 LPM) and offer a wide array of material and porting configurations. 2” non-metallic pumps are often used for transfer, filling, recirculation and batching in Chemical, Industrial and Water/Wastewater treatment markets.
Available with Long-life PTFE diaphragms.
Up to 4 times the life of traditional diaphragm pumps due to the EXP's convoluted diaphragm design
Efficiency - Simul-Shift™ valve provides ultra-positive, reliable shift signal
Reliability - ARO's patented 'Unbalanced' air valve ensures no-stall operation
Versatility - Broad range in materials of construction for optimum fluid compatibility
Environmentally Sound - Bolted construction for leak-free fluid handling and ribless fluid caps to eliminate cracking
Serviceability - Easier service through modular design
Maximum Flow: 184 GPM (696 lpm)
Displacement per cycle: 1.4 gallons (5.3 liters)
Air Inlet (Female): 3/4 - 14 N.P.T.
Fluid Inlet/Outlet: 2” A.N.S.I./DIN Hybrid Flange (Side or Center Ports)
Max. operating pressure: 120 PSI (8.3 bar)
Suspended solids maximum diameter: 1/4” (6.4 mm)
Polypropylene, Side Ported 85.3 lbs (38.7 kg)
Polypropylene, Center Ported 89 lbs (40.4 kg)
PVDF, Center Ported 116.8 lbs (53 kg)
PVDF, Side Ported 110.9 lbs (50.3 kg)
Maximum dry suction lift: 19.5 ft (5.9 m)
Sound Level: 70 PSI 60 Cycles/Min 85.0 db(A)
Muffler Included: 93139
ARO is Fluid Intelligence and a leading worldwide manufacturer of fluid handling products that are expertly engineered to deliver performance and serviceability, enabling our customers to achieve the best total cost of ownership.
